The T50 series air filter regulator is one of the auxiliary devices of pneumatic instruments. After filtering and purifying the air pressure of 0.3~1Mpa from the air compressor, it can adjust any output pressure value within the range of 0~0.2, 0~0.4, and 0~0.8 Mpa to maintain stability. As an auxiliary device for various pneumatic instruments and automatic pneumatic devices, the air source pressure is provided to the unit and other pneumatic equipment.
FEATURES:
| Working medium | Air |
| Connection pipe size | 1/4 |
| Filter accuracy | 5μm |
| Regulating range | 0.05~0.7Mpa |
| Max. working pressure | 1.0Mpa (145psi) |
| Guaranteed pressure resistance | 1.5Mpa (215psi) |
| Working temperature range | -5℃~60℃ |
| Weight | 0.9kg |
| Housing material | Aluminum alloy |
